Performance parameters (Exceeds TIA/EIA-568-A and Cat5 Standard) |
||||||
|
Frequency |
Attenuation |
NEXT |
PSNEXT |
ELFEXT |
PSELFEXT |
RL |
|
(MHz） |
(dB/100m) |
(dB) |
(dB) |
(dB) |
(dB) |
(dB) |
|
1.0 |
1.9 |
100.0 |
97.0 |
98.0 |
96.0 |
26.0 |
|
4.0 |
3.7 |
100.0 |
97.0 |
98.0 |
96.0 |
28.0 |
|
10.0 |
5.6 |
100.0 |
97.0 |
98.0 |
98.0 |
29.0 |
|
16.0 |
7.0 |
100.0 |
97.0 |
96.0 |
96.0 |
30.0 |
|
20.0 |
7.8 |
100.0 |
97.0 |
94.0 |
94.0 |
29.7 |
|
31.3 |
9.7 |
100.0 |
97.0 |
90.0 |
88.0 |
29.6 |
|
62.5 |
14.0 |
100.0 |
97.0 |
84.0 |
82.0 |
27.7 |
|
100.00 |
17.9 |
100.0 |
97.0 |
78.0 |
76.0 |
30.1 |
|
155.0 |
23.6 |
100.0 |
97.0 |
74.0 |
72.0 |
28.7 |
|
300.0 |
31.0 |
95.0 |
92.0 |
64.0 |
62.0 |
27.0 |
|
600.0 |
46.0 |
90.0 |
87.0 |
45.0 |
43.0 |
25.0 |
|
900.0 |
55.0 |
83.0 |
80.0 |
36.0 |
34.0 |
22.0 |
|
1000.0 |
57.0 |
80.0 |
77.0 |
33.0 |
31.0 |
20.0 |
|
Electrical Characteristics |
|
|
Impedance(Ω) |
75±3 |
|
Velocity of Propagation |
83% |
|
Capacitance(pF/m) |
53.1 |
|
Structural Return Loss(≥dB) |
20 |
|
Attenuation [@ 68° F. (20° C)] |
|
|
Frequency(MHz) |
Maximum(dB/100m) |
|
5 |
2.20 |
|
55 |
5.25 |
|
211 |
9.42 |
|
300 |
11.25 |
|
400 |
13.12 |
|
550 |
15.45 |
|
750 |
18.34 |
|
1000 |
21.46 |
|
1450 |
26.20 |
|
1800 |
28.90 |
|
2250 |
32.80 |
|
3000 |
39.00 |
